Multifilament Polyester 3 Strand Mooring Rope

Product Highlights

• Superior Deep-Layer Abrasion Resistance: Traditional twisted architecture provides maximum wear surface depth. Unlike a braided cover which can fuzz, the 3-Strand design forces any abrasion to act against the primary load-bearing material, significantly extending the time before critical strength loss occurs.

• Tide Low-Creep Dimensional Stability: Our pre-stabilized high-tenacity filaments offer a low elongation profile. This ensures precise drift control, keeping your vessel positioned accurately against the fenders during fluctuating tidal cycles or heavy swell—no excessive line stretch means fewer manual tensioning operations for the crew.

• Nylon 100% Wet-Strength Retention: Unlike Nylon, which can lose up to 10-15% of its tensile strength when saturated, Polyester is hydrophobic. It maintains 100% of its rated breaking strength in water. It will not shrink, harden, or swell when drying, ensuring consistent, user-friendly handling and splicing ease.

• Sinking Total Sub-Surface Management : With a high specific gravity of 1.38, this rope is designed to stay submerged below the surface. This prevents interference with surface craft and protects the line from floating debris, adding an extra layer of safety in busy harbor channels.

Certifications

Application Scenario

Specifications

3-Strand Multifilament Polyester (Terylene) Rope
	Diameter (mm)	Circumference Cir (INCH)	Linear densit (Ktex)	Deviation (%)	Theoretical weight (kg/200M)	Min.Breaking   load
						(KN)	(Ton)
	4	1\2	11.8	±10	2.36	2.9	0.3
	6	3\4	27	±10	5.4	5.54	0.57
	8	1	48	±10	9.6	10	1.02
	10	1-1\4	76	±8	15.2	15.6	1.59
	12	1-1\2	110	±8	22	22.3	2.28
	14	1-3\4	148	±8	29.6	31.2	3.18
	16	2	195	±5	39	39.8	4.06
	18	2-1\4	245	±5	49	49.8	5.08
	20	2-1\2	303	±5	60.6	62.3	6.36
	22	2-3\4	367	±5	73.4	74.7	7.62
	24	3	437	±5	87.4	89.6	9.14
	26	3-1\4	512	±5	102.4	105	10.71
	28	3-1\2	594	±5	118.8	120	12.24
	30	3-3\4	682	±5	136.4	134	13.67
	32	4	778	±5	155.6	154	15.71
	36	4-1\2	982	±5	196.4	190	19.39
	40	5	1215	±5	243	235	23.98
	44	5-1\2	1468	±5	293.6	279	28.47
	48	6	1750	±5	350	329	33.57
	52	6-1\2	2050	±5	410	384	39.18
	56	7	2380	±5	476	439	44.8
	60	7-1\2	2730	±5	546	489	49.9

Production Scope: The structure of mooring rope can be divided into 3-strand, 6-strand, 8-strand and 12-strand.  The raw material includes: polypropylene, polyester, nylon, Super high tensile strength polyethylene, aramid fibre and synthetic fibre.  Diameter scope: Ф6mm ~ Ф140mm are available.

Package
